ABB 07 SK 90 R1(07SK90R1) GJR5250200R1 Interface Cable

General Information

• Product Name: ABB 07SK90R1 Interface Cable
• Product ID: GJR5250200R1
• Compatible Systems:
  • Advant Controller 31: 07KR91, 07KT9x, 07KP90
  • ABB Procontic T200: 07KP62, 07KP64
• Purpose:
  • Connects peripheral units to the 9-pin serial interfaces of AC31 basic units and T200 communication processors.
  • Supports programming mode and active mode operations.
  • Includes a 25-pin to 9-pin adaptor for peripherals with 9-pin interfaces.

Mechanical Design

• Plug 1: 9-pin SUB-D male (for 07KP6x, 07KR91, 07KT9x)
  • Metal-plated housing with shield connection.
• Plug 2: 25-pin SUB-D female (for peripheral unit)
  • Secure mounting with screws.
• Cable Type: LICYCY 5 x 0.14/15
• Included Adaptor: 25-pin male to 9-pin female

Technical Data

This ABB 07SK90R1 Interface Cable is specifically designed for reliable communication between AC31 basic units, T200 communication processors, and peripheral devices in industrial automation environments.
