ABB 5SHY35L4520 AC10272001R0101/5SXE 10-0181 IGCT Module

Product Information

• Model: 5SHY35L4520
• Part Number: AC10272001R0101 / 5SXE 10-0181
• Category: Asymmetric Integrated Gate-Commutated Thyristor (IGCT)
• Voltage Rating (VDRM): 4500V
• Current Rating (ITGQM): 4000A
• Mounting Force: 40kN
• Weight: 2.9 kg
• Dimensions: 439mm × 173mm × 41mm

Features

• ✔ High snubberless turn-off rating
• ✔ Optimized for medium frequency (<1kHz)
• ✔ High electromagnetic immunity
• ✔ Simple control interface with status feedback
• ✔ Supports both AC and DC power supply
• ✔ Option for series connection (contact factory)

Additional Details

• Country of Origin: Switzerland
• Customs Tariff Code: 85413000
• Stock Location: Malmö, Sweden
• Product Type: Control System Accessory
• Replacement for: 5SHY35L4510

Application

Ideal for industrial drives, railway traction, power transmission, and high-power conversion systems.
