ABB DI562 S500-eCo Digital Input Module (1TNE968902R2102)

Overview

The ABB DI562 is a 16-channel digital input module designed for S500-eCo PLC systems. It supports sink/source input configurations at 24V DC, providing reliable signal processing for industrial automation applications.

Key Features

• Model: DI562
• Number of Digital Inputs: 16
• Input Voltage Type: AC/DC (24V DC sink/source)
• Input Current: 5 mA
• Maximum Input Voltage: 0 – 30V
• Connection Type: Pluggable

Applications

• Industrial automation and PLC control systems
• Distributed I/O configurations in S500-eCo systems
• Reliable digital signal acquisition for machine control

Technical Specifications

• Response Delay Time: 8 ms
• Degree of Protection: IP20
• Operating Temperature: 0°C to +60°C
• Storage Temperature: -40°C to +70°C

Dimensions & Weight

• Net Weight: 0.116 kg
• Net Dimensions:
  • Depth: 135 mm
  • Height: 74 mm
  • Width: 34 mm
• Package Weight: 0.215 kg

Compliance & Ordering Information

• HS Code: 85371091
• UNSPSC: 32151705
• Country of Origin: China
• Minimum Order Quantity: 1 piece
• WEEE Category: Small Equipment (No external dimension exceeds 50 cm)
• SCIP Reference: 2a5298d5-fdc0-42f2-82a6-f96a09eb394f

The ABB DI562 Digital Input Module is an efficient and compact solution for industrial control applications, offering high reliability and seamless integration into S500-eCo automation systems.

---
