Allen-Bradley CompactLogix 5069-L320ER Ethernet Controller

High-Speed Compact Controller for Demanding Applications

The 5069-L320ER is a powerful controller in the Allen-Bradley CompactLogix 5380 family. It is ideal for high-performance, mid-sized control applications with tight integration into Rockwell Automation systems.

Fast Communication and Flexible Networking

Equipped with two 1 Gb Ethernet ports, this controller ensures fast, reliable communication. It supports EtherNet/IP and USB for versatile connectivity and diagnostics.

Efficient Processing and Built-In Memory

The quad-core processor delivers fast execution for real-time tasks. With 2MB of user memory, it handles complex programs with ease.

Compact Design with Wide Power Support

Its compact footprint fits into tight spaces, while its wide power input range supports both DC and AC systems. The controller also meets ATEX/IECEx standards for hazardous environments.

Technical Specifications

• Series: CompactLogix 5380
• Model: 5069-L320ER
• Lifecycle Status: Active
• Processor: Quad Core
• Memory: 2MB
• Communication: EtherNet/IP, USB
• Ethernet Ports: 2 × 1 Gb
• Isolation: 300V continuous; no isolation between ports
• Power Supply:
  • MOD Power: 18–32V DC
  • SA Power: 0–32V DC / 0–240V AC, 47–63 Hz
  • ATEX/IECEx compliant: 125V AC max
• Channels: 0
• Dimensions:
  • Depth: 136.81 mm (5.39″)
  • Height: 123 mm (4.84″)
