The Bachmann PTAI216 is a versatile temperature recording module designed for precise measurements in various applications. It features multiple analog input channels and dedicated inputs for Pt100/Pt1000 sensors, ensuring reliable temperature data collection.
Features
- 4 analog inputs: ±10 V / ±1 V / 0 to 20 mA
- 12 inputs for Pt100/Pt1000 sensors
- Supports single-ended or differential inputs for analog signals
- Utilizes 2-wire inputs for Pt100/Pt1000 sensors
- Resolution: 14 bit (analog inputs) / 12 bit (Pt100/Pt1000)
- Sample time: 2.5 ms (analog inputs) / 480 ms (Pt100/Pt1000)
- Galvanically isolated channels
- Wire break detection for inputs
- Monitoring of external power supply
Specifications
Voltage Inputs
- Quantity: Max. 4
- Input Type: Single-ended or differential
- Input Voltage: ±1 V or ±10 V
- Input Impedance: > 33 kΩ
- Input Filter: 170 Hz (low pass 1st order)
- Digital Resolution: 14 bit
- Allowed Common Mode Voltage: Max. ±1 V
- Error at Operating Temperature:
- ±1 V: 25 °C → ±0.5 %
- ±1 V: 0 to +60 °C → ±0.5 %
- ±1 V: -30 to +60 °C → ±0.5 %
- ±10 V: 25 °C → ±0.1 %
- ±10 V: 0 to +60 °C → ±0.15 %
- ±10 V: -30 to +60 °C → ±0.3 %
- Cross-talk Attenuation: > 60 dB
- Sample Time: 2.5 ms
Current Inputs
- Quantity: Max. 4
- Input Current: 0 to 20 mA
- Input Impedance: 243 Ω
- Digital Resolution: 14 bit
- Max. Input Current: 35 mA (destruction limit)
- Error at Operating Temperature:
- 0 to 20 mA: 25 °C → ±0.2 %
- 0 to 20 mA: 0 to +60 °C → ±0.2 %
- 0 to 20 mA: -30 to +60 °C → ±0.3 %
- Sample Time: 2.5 ms
Pt100/Pt1000 Inputs
- Quantity: 12
- Input Type: 2-wire technology
- Temperature Range: -100 to +300 °C
- Constant Current via Sensor:
- Pt100: 3 mA
- Pt1000: 0.3 mA
- Digital Resolution: 12 bit
- Value of the LSB: 0.1 K
- Averaging: Over 16 values per 480 ms
External Power Supply
- Galvanic Isolation from System: 500 V
- Voltage Range: 18 to 34 VDC
- Current Consumption Internal: Normally 70 mA at 24 VDC
Approvals / Certificates
- General: CE, cULus, CCC
- Marine: DNV, LR, ABS, BV
- Ambient Conditions: Standard ColdClimate
- Operating Temperature: -30 to +60 °C
- Relative Humidity (Operation): 5 to 95 % (without condensation); 5 to 95 % (with condensation)
- Storage Temperature: -40 to +85 °C
- Relative Humidity (Storage): 5 to 95 % (with condensation)
- Pollution Degree (IEC 60664-1): 2 (without condensation); 2
Order Codes
| Item | Item No. | Description |
|---|---|---|
| PTAI216 | 00010708-00 | Temp.-recording module; 12x Pt100/1000; 4x In ±10V ±1V 20mA; 14bit; 0.25 %; isolated |
| PTAI216 CC | 00017456-00 | Like PTAI216; ColdClimate |
| KS-PTAI216 B+C | 00012599-50 | Terminal set cage clamp small (1x KZ 51/02; 4x KS 35/14) with labeling strip and coding elements (not for new developments) |
| KZ-PTAI216 B+C | 00026126-00 | Terminal set Phoenix cage clamp (1x KZ 51/02; 4x KZ 35/14) with labeling strip and coding elements |
| SS-PTAI216 B+C | 00012010-50 | Terminal set Phoenix screw side (1x KZ 51/02; 4x SS 35/14) with labeling strip and coding elements |
| SV-PTAI216 B+C | 00010870-50 | Terminal set Phoenix screw frontside (1x SV 51/02; 4x SS 35/14) with labeling strip and coding elements |
