Bently Nevada 106M1079-01 | Universal AC Power Supply Module

The 106M1079-01 Universal AC Power Supply Module is a high-performance power supply designed for use in a variety of industrial environments, including both non-hazardous and hazardous areas. It is equipped to handle a wide range of input voltages and ensures reliable power distribution for monitoring systems, with the ability to accommodate redundant power supplies in the same rack.

Key Features:

• Universal AC Input: Compatible with both non-hazardous and hazardous areas, supporting a wide input voltage range.
• Redundant Power Supply Capability: Both slots in the rack can hold a power supply, allowing for redundant operation to ensure continuous performance.
• LED Indicator: The front panel features an OK LED, indicating when the power supply is functioning properly.

Specifications:

Inputs:

• Voltage Options:
  • Non-Hazardous Areas: 85 to 264 Vac RMS.
  • Hazardous Areas: 85 to 250 Vac RMS, 120 to 373 Vac pk.
  • Nominal: 110 to 220 Vac.
• Input Frequency: 47 to 63 Hz.

Current Draw:

• Full Rack Current Draw:
  • 2.8 A RMS (maximum) for universal voltage AC.

Outputs:

• Front Panel LEDs:
  • Supply OK LED: Indicates proper operation of the power supply.

Physical:

• Power Supply Module Dimensions:
  • Height: 120.7 mm (4.75 in)
  • Width: 50.8 mm (2.0 in)
  • Depth: 251.5 mm (9.9 in)
• Weight: 1.39 kg (3.07 lbs)

Rack Space Requirements:

• Power Supply Module:
  • Occupies two half-height slots located on the left side of the rack.
  • Both slots can accommodate one power supply each, enabling redundancy for continuous power supply.

Applications:

• Ideal for use in monitoring systems that require a reliable and robust power source, particularly in environments where continuous operation is critical.
• Suitable for redundant power configurations in systems that need to operate without interruption, enhancing the reliability of critical machinery and systems in both industrial and hazardous environments.
