Bently Nevada 330850-90-05 | 3300 XL Proximitor Sensor

The 330180-90-00 Proximity Sensor is designed for use with 3300-series or 3300 XL probes. This sensor ensures reliable performance in industrial applications, offering excellent sensitivity and durability under harsh conditions.

Ordering Information:

• A: Total Length and Mounting Option:
  90 – 9.0 meters (29.5 feet) system length, panel mount configuration.

• B: Agency Approval Option:
  00 – Not required.

Key Specifications:

• Input:
  Accepts one non-contacting 3300-series 5 mm or 3300 XL 8 mm Proximity Probe and Extension Cable.

• Power:

  • Requires -17.5 Vdc to -26 Vdc when installed with a non-incendive circuit, with a maximum consumption of 12 mA.
  • Requires -23 Vdc to -26 Vdc with barriers.
  • Operation at a more positive voltage than -23.5 Vdc can result in reduced linear range.

• Supply Sensitivity:
  Less than 2 mV change in output voltage per volt change in input voltage.

• Output Resistance:
  50 Ω.

• Material:
  A308 aluminum, providing durability for the sensor.

• Weight:
  246 g (8.67 oz).

• Temperature Range:

  • Operating Temperature: -52°C to +100°C (-62°F to +212°F).
  • Storage Temperature: -52°C to +105°C (-62°F to +221°F).

Key Features:

• Durable Construction:
  Made from A308 aluminum, this sensor is built to withstand tough environments while maintaining high performance.

• High Sensitivity:
  Provides excellent response to small vibrations, essential for monitoring machinery health.

• Easy Installation:
  The sensor supports panel mounting and works with 3300-series or 3300 XL probes for flexible installation options.

• Environmental Protection:
  The sensor can operate in extreme conditions, with an operating temperature range of -52°C to +100°C.
