Honeywell C7076A1007 Ultraviolet Flame Detector

Product Overview

The Honeywell C7076A1007 is a high-performance Ultraviolet Flame Detector designed for reliable detection of flame presence in gas and oil-fired burners. This detector features adjustable sensitivity and dynamic self-checking for optimal performance.

Key Features

• Ultraviolet flame detection for accurate and reliable performance

• Adjustable sensitivity to suit various burner applications

• Dynamic self-checking for consistent detection and system safety

• Suitable for gas and oil-fired burners in industrial applications

Technical Specifications

• Part Number: C7076A1007/U

• Voltage: 120 V AC, 50/60 Hz

• Power Consumption: 7.0 W

• Electrical Connections: Terminal block

• Vibration: 0.5 G max

• Mounting: 1 in. NPT

• Ambient Temperature Range: -40°F to +160°F (-40°C to +71°C)

Approvals

• CSA Certified: Master Report LR1620

• Swiss RE Acceptable

• Factory Mutual Approved: Report No. FM26980

Shipping Information

• Shipping weight: 4 kg
