ICS TRIPLEX T8310 Trusted TMR Expander Processor

The Rockwell T8310 Trusted® TMR Expander Processor Module is a critical component for extending the Trusted control system’s capabilities. It integrates with the Trusted Expander Chassis, serving as the interface between the Expander Bus and the Expander Chassis Backplane. Utilizing Unshielded Twisted Pair (UTP) or Fiber Optic connections, it ensures fault containment and system reliability, adhering to the Trusted system’s fault-tolerant, high-availability design.

Key Features

TMR Fault Tolerance: Operates with a 3-2-0 fault-tolerant configuration using HIFT (Hardware Implemented Fault Tolerant) architecture.
Diagnostics and Fault Handling: Features hardware/software testing for fast fault detection and response.
Hot Replacement: Supports online replacement without disturbing system operations.
Front Panel Indicators: Displays health and operational status.
Modular Configuration: Supports automatic/manual repair strategies for enhanced system availability.

Specifications

Electrical Characteristics

Backplane Supply:
- Voltage: 20 Vdc to 32 Vdc
- Power Dissipation: 45 W
Field Supply: Not applicable
Isolation:
- 50 V Basic Insulation between module and backplane supply

Communication

Maximum Expander Communication Distance:
- 30 m using TC-301 Copper Cable
- 10 km using T8314 Fiber TX/RX Units

Environmental Specifications

Operating Temperature: 0 °C to +60 °C (+32 °F to +140 °F)
Storage Temperature: -25 °C to +70 °C (-13 °F to +158 °F)
Relative Humidity (Operating/Storage): 10% – 95%, non-condensing

Dimensions and Weight

Height: 266 mm (10.5 in)
Width: 31 mm (1.2 in)
Depth: 303 mm (12.0 in)
Weight: 1.33 kg (2.9 lb)

Environmental and EMC Standards

Mechanical Durability

Vibration:
- 5–8.4 Hz: 3.5 mm
- 8.4–150 Hz: 1g
Shock: 15 g, 11 ms

Electromagnetic Compatibility (EMC)

Radiated & Conducted Emissions: Compliant with CISPR 11, Class A
ESD Immunity: ±6 kV (contact), ±8 kV (air)
Radiated RF Immunity:
- 10 V/m, 80 MHz–2.7 GHz (1 kHz 80% AM)
- 3 V/m, 2.7 GHz–6 GHz (1 kHz 80% AM)
EFT/Burst Immunity:
- DC Power: ±4 kV
- I/O and Communication: ±1 kV
Surge Immunity:
- DC Power: ±4 kV line-earth, ±2 kV line-line
Conducted RF Immunity: 10 V rms, 150 kHz–100 MHz

Magnetic Immunity:

Compliant with IEC 61000-4-8:2010 (30 A/m).
