The Trusted® T8850 40 Channel Output Field Termination Assembly (FTA) acts as the interface between various Trusted Triple Modular Redundant (TMR) output modules (including both digital and analogue) and field devices. The module provides high reliability, robust performance, and simple integration, making it ideal for industrial applications requiring fault tolerance, redundancy, and secure operation.
Key Features
- 40 Output Channels: Designed to handle 40 output channels per FTA, accommodating a variety of field devices for both analogue and digital outputs.
- Industry Standard Connections: Supports 2-wire connections for field devices, ensuring broad compatibility with various equipment.
- DIN Rail Compatibility: The FTA is compatible with standard DIN rail mounts for easy installation and integration.
- Screw Clamp Terminals: Offers secure connections for both field and power supplies, ensuring reliable operation.
- SmartSlot Connection: Enables ‘one to many’ hot replacement of output modules without system downtime.
- Isolated Groups: The FTA has five isolated groups of eight channels for enhanced protection and noise reduction.
- Field Power LED Indicators: Provides onboard LEDs to indicate the integrity of the field power supply.
- Wide Wire Size Range: Supports a wide range of field terminal wire sizes from 12 AWG to 28 AWG.
Specifications
Electrical Characteristics
- Field Supply: 60 Vdc maximum (via T8290)
- Power Dissipation: 0.5 W per power group
- Isolation:
- Power Group to Power Group: 50 V Reinforced (continuous)
- Field Common: 50 V Reinforced (continuous)
- Channel to Channel (within Power Group): None
- Basic Fault Isolation: 250 V Basic (fault), tested at 2436 Vdc for 60 s
- Fusing: None (relies on external protection)
Environmental Characteristics
- Operating Temperature: 0 °C to +60 °C (+32 °F to +140 °F)
- Non-Operating Temperature: -25 °C to +70 °C (-13 °F to +158 °F)
- Relative Humidity: 10% to 95%, non-condensing
Environmental Compliance and Immunity
- Vibration: IEC 60068-2-6 (Operating): 5 to 8.4 Hz at 3.5 mm, 8.4 to 150 Hz at 1g
- Shock (Operating): IEC 60068-2-27: 15 g, 11 ms
- Radiated & Conducted Emissions: CISPR 11, Class A (Radiated to 6 GHz)
- Electrostatic Discharge (ESD) Immunity: ±6 kV contact, IEC 61000-4-2:2009
- Surge Immunity: IEC 61000-4-5: ±4 kV line-earth, ±2 kV line-line for DC and AC power fields
- Conducted RF Immunity: IEC 61000-4-6: 10 V rms, 150 kHz to 100 MHz
- Magnetic Immunity: IEC 61000-4-8: 30 A/m
Dimensions and Weight
- Height: 110 mm (4.33 in)
- Width: 360 mm (14.17 in)
- Depth: 68 mm (2.67 in)
- Weight: 950 g (2.1 lb)
Important Notes
- Power Supply Connection: When using a field voltage range above 32 Vdc, the field supply must not be connected to P1 (Pins 1, 3, 5, 7, 9). Output positive connections should instead be routed through the output power distribution unit (OPDU), Trusted Part Number T8290.
