Siemens 6DR5310-0NG00-0AA0 - SIPART PS2 Smart Electropneumatic Positioner

Product Overview – 6DR5310-0NG00-0AA0

The Siemens SIPART PS2 electropneumatic positioner, model 6DR5310-0NG00-0AA0, is designed for single-acting pneumatic actuators (both linear and part-turn). It uses a 4–20mA (3/4-wire) signal and is enclosed in a durable polycarbonate housing. This specific version comes without explosion protection and is ideal for standard automation environments.

Key Features of Siemens 6DR5310-0NG00-0AA0

Model Number: 6DR5310-0NG00-0AA0
Input Signal: 4–20 mA (3/4-wire)
Fail-Safe Function: Yes – depressurizes actuator upon auxiliary power failure
Actuator Compatibility: Single-acting pneumatic (linear and rotary)
Housing Material: Polycarbonate
Electrical Connection Thread: M20x1.5
Pneumatic Connection Thread: G 1/4
Explosion Protection: Not included
Limit Monitor: Not included
Option Module: Not included
Manometer Block / Booster: Not included
Languages (Instructions): English, German, Chinese

Technical Details – Siemens 6DR5310-0NG00-0AA0

Net Weight: 0.900 kg
Dimensions (Packaging): 167 mm x 259 mm x 144 mm
Estimated Delivery Time: 4 Working Days
Country of Origin: France
EAN: 4019169847049

Lifecycle & Replacement

Product Lifecycle Status: Discontinued (Effective: 2024-10-01)
Recommended Replacement Model: Siemens SIPART PS2 – 6DR50* series

Compliance

RoHS Compliant Since: 2016-12-31
WEEE Directive: Yes (2012/19/EU)
REACH: Compliant
Export Control: ECCN: N / AL: N

Why Choose Siemens 6DR5310-0NG00-0AA0?

This specific model offers a cost-effective and reliable solution for actuator positioning without requiring explosion-proof certification. It is a trusted part in many automation environments where fail-safe operation is critical.
