VM600 CMC16 200-530-023-014/200-530-100-014 | VIBRO METER Condition Monitoring Card

The VIBRO-METER 200-530-023-014/200-530-100-014 CMC 16 Condition Monitoring Card is the central element in Vibro-Meter’s VM 600 series Condition Monitoring System (CMS). This intelligent front-end Data Acquisition Unit (DAU) is designed to work with the VM 600 CMS software to acquire, analyze, and transmit results to a host computer via the VM 600 series CPU M module with Ethernet controller or directly through serial links.

Features

Programmable Inputs: Accepts signals for speed, phase reference, vibration (acceleration, velocity, or displacement), dynamic pressure, air gap rotor and pole profile, dynamic signals, and quasi-static signals.
Signal Routing: Inputs from adjacent Machinery Protection Cards (MPC 4) via VM 600 ‘Raw Bus’ and ‘Tacho Bus’ or externally via screw terminal connectors on the IOC 16T.
Signal Conditioning: The IOC 16T modules provide signal conditioning and EMC protection, routing inputs to the CMC 16.
On-board Processing: Features include acquisition control, time to frequency domain conversion (FFT), band extraction, unit conversion, limit checking, and communication with the host system.

Data Acquisition and Processing

Channels: 16 programmable tracked anti-aliasing filters and Analog-to-Digital Converters (ADC).
Data Outputs: Supports RMS, peak, peak-peak, and true peak values, with configurable bands based on acquired spectra.
Threshold Settings: Data transmission to host computer occurs only on exceptions when changes exceed defined thresholds.
Long-term Data Trends: Long-term averages are calculated for trend analysis over multiple years.

Event Generation

Alarm Settings: Events are generated based on configurable limits, rate-of-change alarms, or deviations from baselines.
Adaptive Monitoring: Alarm set points can be dynamically adjusted based on machine parameters like speed and load.

Operational Capabilities

Transient Mode: Higher density logging based on configurable time and speed intervals.
Vibration Measurement: Operates in speed ranges from 15 rev/min to 30,000 rev/min.
High-resolution Data Acquisition: Capable of capturing scheduled intervals or alarm detection (waveforms, spectra, orbits).
Oscilloscope Mode: Extended capture of time-based data can be triggered for in-depth analysis.

Specifications

Speed/Phase Reference Input

Triggering Method: Rising or falling edge
Input Voltage Range: 1 to 24 V pulse
Frequency Range: 0.25 to 10,000 Hz
Maximum Pulses per Revolution: 128
Machine Speed Resolution: ±1 rev/min

Vibration and Analog Inputs

A/D Converter: 14 bits per channel
Maximum Sampling Rate: 100 kHz
Accuracy: 1% of input FSD

Background Logging Acquisition

Order Tracking Range: 15 RPM to 30,000 RPM
FFT Resolution: 400 lines

Transient Acquisition

Maximum Transient Duration: 18 hours 12 minutes
Maximum Number of Points Available: 270

On-board Buffer Storage

RAM Memory: 1 MByte

Communications

Type: D16 / A24 slave mode
Serial Communication: RS-485 multi-drop line

Power Supply

Supply Voltage: 5 VDC ± 5%
Consumption: 15 W

Environmental Specifications

Operating Temperature: -25°C to +65°C
Humidity: 0 to 90% non-condensing

Physical Dimensions

Height: 6 U (262 mm)
Width: 20 mm
Depth: 187 mm
Weight: 0.35 kg

Ordering Information

To order, please specify:

Type Designation: CMC 16 Condition Monitoring Card
Ordering Number: 200-530-SSS-HHh
Note: “SSS” represents the firmware version and “HHh” the hardware version.
